Digital Inverter AC/DC Pulsed TIG Welding Machine

, WSME 315 /500/630/700 (compact/separate)

Digital Inverter Arc Pulsed Welding Machine / AC/DC Pulsed TIG Welding Machine / Digital Pulsed TIG Welding Machine

Characteristics
AC TIG, AC pulsed TIG, DC TIG, DC pulsed TIG and DC MMA welding functions
Soft switch technology
Microcomputer control technology allows the arc welding machine to save 10 groups of welding parameters at a time
Multi-functional: AC wave width, positive and negative half wave amplitude.
The AC frequency is adjustable

Suitable welding materials:
aluminum, aluminum alloy, carbon steel, alloy steel, stainless steel, copper, and titanium
Application fields:
machinery industry, petroleum industry, chemical industry, shipbuilding industry, vehicle industry, electric power construction and decorations

Technical Specifications
Model WSME315 WSME500 WSME630 WSME700
Rated input power 3-Phase,220V/380V/415V/440V, 50/60Hz 3-Phase,380V/415V/440V, 50/60Hz
Rated input capacity (kVA) 14.5 26 36.2 39.5
Rated input current (A) 22 39 55 60
Rated output current (A) 10-315 20-500 20-630 20-700
Rated output voltage (V) 10.4-22.6 10.8-30 10.8-34 10.8-34
Open circuit voltage (V) 64 69 73 94
MMA thrust current range (A) 20-315 20-500 1-200 1-200
MMA arc current range (A) 1-200 1-200 20-500 20-700
Striking current adjusting range (A) 20-160 20-160 20-160 20-160
Arc current adjusting range (A) 10-315 20-500 20-500 20-700
Base value current adjusting range (A) 10-315 10-500 20-630 20-700
Peak current adjusting range (A) 10-315 20-500 20-630 20-700
Pulse duty ration (%) 1-99 1-99 1-99 1-99
Impulse frequency (Hz) 0.1-20
Clearance rate range (%) -40~+40
AC bias range (%) -50~+30
AC frequency range (Hz) 20-200 20-100
Ahead of time (S) 0.1-5
Lag time (S) 1-10
Ramp time (S) 0.1-10
Slow down time (S) 0.1-10
Rated duty cycle (%) Room temperature 40℃ 60
Protection grade IP21S
Insulation class F
Power factor 0.83
Efficiency (%) 80
Dimension (L*W*H) (mm) WSME315S:690×335×670 WSME500S:695*360*830 700*370*780 995*370*810
WSME315C:1118*660*1124 WSME500C:1123*660*1241
Weight (kg) WSME315S:60 WSME315S:75 85 96
WSME315C:85 WSME500C:100

*For WSME315/500, there is a choice of compact (integrated) model.
