Mini Gantry Style CNC Flame/Plasma Tube and Plate Cutting Machine

, HCZG Series

Plate Cutting Machine / Mini Gantry Style CNC Plate Cutting Machine / Plasma Tube and Plate Cutting Machine

Characteristics
Multiple models of the mini gantry style CNC flame cutting machines are available in a variety of specifications, including the cutting range, and choice of vertical or lateral rail track.
The plate cutting machine uses a bilateral servo drive, reliable operation and a high cutting precision.
The gantry structure has undergone stress relieving process, and is both deformation resistant and durable.The side open beam structure is easy to maintain.
The universal CNC system is easy to learn and operate.
With CNC programming, this machine is capable of cutting any shape, features a break point memory and reduces secondary processing, thus, increases overall productivity.
The nesting software can transform CAD shapes or computer drawn shapes into a G code for cutting. The system then automatically transforms the G code into a cutting software to fulfill an automated cutting process with shared edges.
This tube and plate cutting machine features a brand new design that is aesthetically pleasing, practical and economical.
The tube-plate integrated machine is capable of automatic shifting between the tube and plate.

Technical Specifications
Model number HCZG-2660FP
Voltage input 220V
Power frequency 50Hz
Power rating 3-5kW
Liquid Crystal Display (LCD) 10.4 inches
Largest cutting width 2600mm
Largest cutting length 6000mm
Flame cutting thickness Piercing cutting: 6-60mm; Edge cutting: 6-120mm
Maximum speed 0-5000mm/min
Torch lifting distance ≤ 120mm
Plasma Piercing cutting thickness See plasma specifications
Plasma cutting thickness range See plasma specifications
Precision Compile with JB/T5102-1999
Linear positioning precision ± 0.5mm/3m
Linear repeat precision ± 0.5mm/3m
Speed deviation ± 5%
Cutting plane roughness Ra ≤ 12.5μm
Cutting pipe size range Φ 50-300mm
Tube length ≤ 6000mm
Tube ovality ≤ 2%
Workpiece rotating speed 0-25 r/min
Busbar repeat positioning accuracy ≤± 0.5mm
Tube supporting rack 3
Name Diagram Name Diagram
Tube straight cutting Eccentric orthogonal main pipe hole cutting
Tube inclined cutting Orthogonal branch pipe tips cutting
Oblique pipe end cutting Oblique main pipe hole cutting
Eccentric orthogonal branch pipe tips cutting Eccentric oblique main pipe hole cutting
Eccentric oblique branch pipe tip cutting End plane notching cutting (rectangular notch, semicircle notch, round edge rectangular notch)
Multiple pipes intersecting branch pipe tip cutting End plane eccentric notching cutting (rectangular notch, semicircle notch, round edge rectangular notch)
Multiple pipes intersecting branch pipe tip cutting Mid notching cutting (rectangular notch, semicircle notch, round edge rectangular notch)
Parallel branch pipe tip cutting Mid eccentric notching cutting (rectangular notch, semicircle notch, round edge rectangular notch)
Tube branch pipe tip cutting Orthogonal main pipe hole cutting
